Advantages
· Easy assembly
· Non-contact measurement
· High sensitivity
· Maintenance-free construction
· Resistant to dust, pressure, temperature, gas
Application Fields
MICROPULS 59 is an ideal sensor for measurement especially of granular solids under difficult conditions. Electronic amplifier is configured for hard conditions. By this means MICROPULS 59 is the most effective radar which is capable of measuring up to 30m of cement, aggregate, plastic, coal, lime, mineral, sawdust, wood chip, food powders, feed, grain, granule and like all similar bulk solids especially under dusty conditions.
TECHNICAL SPECIFICATIONS
| Measurement range |
Up to 30 m |
| Accuracy |
±10 mm |
| Process connection |
Threaded G1½ A or 1½ NPT, Flange starting from DN 50 |
| Process pressure |
-1 … 40 bar |
| Process temperature |
-40...150 °C (optional -60...+200 °C) |
| Ambient, storage and transport temperature |
-40 … +80 °C |
| Operation voltage |
14.… 36 V DC (optional 220V AC) |
