Advantages
· Easy assembly
· Non-contact measurement
· High sensitivity
· Maintenance-free construction
· Resistant to steam, pressure, temperature, gas
Application Fields
MICROPULS 56 is an ideal sensor for measurement of especially aggressive liquids under difficult conditions. Electronic amplifier is configured for difficult conditions. By this means MICROPULS 56 is the most effective radar according to the measurement range under difficult, steamy and humid conditions. With this feature it’s the most ideal sensor which is capable of measuring up to 30m of all kinds of chemical compounds, aggressive medium like acid, caustic and like all similar liquids.
TECHNICAL SPECIFICATIONS
| Measurement range / freq |
Up to 30 m / 26 GHz |
| Accuracy |
±3 mm |
| Process connection |
Threaded G1½ A or 1½ NPT, Flange starting from DN 50 |
| Process pressure |
-1 … 40 bar |
| Process temperature |
-40...150 °C (optional -60...+400 °C) |
| Ambient, storage and transport temperature |
-40 … +80 °C |
| Operation voltage |
14.… 36 V DC (optional 220V AC) |
