Advantages
· Easy assembly
· Non-contact measurement
· High sensitivity
· Maintenance-free construction
· Resistant to steam, moisture, temperature, gas
Application Fields
MICROPULS 55 is an ideal sensor for measurement of especially aggressive liquids. Electronic amplifier is configured for difficult conditions. By this means MICROPULS 55 is one of the most useful sensors which is capable of measuring up to 30m of especially ardous liquids, aggressive medium like acid, caustic, all kinds of chemical compounds and like all liquids. Due to small space requirement, small blanking measurment zone and easy mountability, it’s particularly preferred for use in small vessels.
TECHNICAL SPECIFICATIONS
| Measurement range |
Up to 30 m |
| Error margin |
±5 mm |
| Process connection |
Threaded G1½ A or 1½ NPT, Flange starting from DN 50 |
| Process pressure |
-1 … 3 bar |
| Process temperature |
-40...130 °C |
| Ambient, storage and transport temperature |
-40 … +80 °C |
| Operation voltage |
14… 36 V DC (optional 220V AC) |
