Advantages
· Easy assembly
· Non-contact measurement
· High sensitivity
· Maintenance-free construction
· Resistant to steam, pressure, temperature, gas
Application Fields
MICROPULS 52 is an ideal sensor for measurement of especially aggressive liquids under difficult conditions up to +150°C . Electronic amplifier and increased sensitivity is configured for difficult conditions. By this means MICROPULS 52 is one of the most useful sensors which is capable of measuring up to 30m of especially ardous liquids, aggressive medium like acid, caustic, all kinds of chemical compounds and like all liquids. Measurement can also be made without drilling the vessel at low di-electric constant plastic or derivative vessels.
TECHNICAL SPECIFICATIONS
| Measurement range / frequency |
Up to 30 m / 6 Ghz |
| Accuracy |
±8 mm |
| Process connection |
Flange from DN50 |
| Process pressure |
-1 … 16 bar |
| Process temperature |
-40...150 °C |
| Ambient, storage and transport temperature |
-40 … +80 °C |
| Operation voltage |
14.… 36 V DC (optional 220V AC) |
